P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

طريقة التحكم:يدوي

الصمام:3 بكرات

معدل التدفق المقنن:120 لتر/دقيقة (31.7 جالون أمريكي/دقيقة)

أقصى ضغط:250 بار (3600 رطل لكل بوصة مربعة)

منفذ الدخول:G1

منفذ الخروج:G1

حجم المنفذ:G1

العلامة التجارية:BXHS

نوع المنتج:صمام اتجاهي أحادي الكتلة

سلسلة المنتجات:سلسلة P120 صمام اتجاهي أحادي الكتلة

حجم العبوة:37*37*18

الوزن الإجمالي:24.10 kg

التوفر: متوفر بالمخزن

1327 شخصاً يشاهدون هذا المنتج

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support drawing image

The P120-G1-OT Hydraulic Forward And Reverse Valve is a high-performance, manual control monoblock valve designed for a variety of construction, material handling, and industrial applications. It features a 3-section design, 120 L/min rated flow, and a maximum pressure of 250 bar.

سلسلة P120 صمام اتجاهي أحادي الكتلة بارامترات
طريقة التحكم يدوي, كابل, ذراع تحكم, يدوي وذراع تحكم
الصمام 1 بكرة, 2 بكرة, 3 بكرات, 4 بكرات
معدل التدفق المقنن 120 لتر/دقيقة (31.7 جالون أمريكي/دقيقة)
أقصى ضغط 250 بار (3600 رطل لكل بوصة مربعة)
منفذ الدخول G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
منفذ الخروج G1, SAE 16, 1 NPT, M36×2
حجم المنفذ G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
المقطع المقطع 1, المقطع 2, المقطع 3, المقطع 4
نوع البنية صمام أحادي الكتلة
نطاق درجة الحرارة المحيطة -40 درجة مئوية إلى +80 درجة مئوية (-40 درجة فهرنهايت إلى +176 درجة فهرنهايت)
نطاق اللزوجة التشغيلية 15 - 75 مم²/ث (15 سنتيستوك إلى 75 سنتيستوك)

This P120 Series hydraulic valve is a 3-section, manual control monoblock valve with a rated flow of 120 L/min and a maximum pressure of 250 bar. It is ideal for use in a wide range of applications, including construction equipment (telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders), material handling equipment (telehandlers, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers), and agricultural machinery. The valve operates with an operating viscosity range of 15 - 75 mm²/s and is suitable for ambient temperatures ranging from -40°C to +80°C. The P120-G1-OT valve offers reliable performance and durability, making it an excellent choice for demanding applications.
