Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump

الإزاحة:64.6 سم³/دورة

الضغط المقنن:16 ميجا باسكال (2320 رطل لكل بوصة مربعة)

أقصى ضغط:17 ميجا باسكال (2465 رطل لكل بوصة مربعة)

أقصى سرعة:2200 دورة في الدقيقة

الدوران:ثنائي الاتجاه

العلامة التجارية:BXHS

نوع المنتج:مضخة التروس الهيدروليكية

سلسلة المنتجات:سلسلة P21 مضخة التروس الهيدروليكية

حجم العبوة:45*25*18

الوزن الإجمالي:16.00 kg

التوفر: متوفر بالمخزن

164 شخصاً يشاهدون هذا المنتج

Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump

Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump

Precision Engineered P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump drawing image

This P21 Series Hydraulic Gear Pump features a 64.6 cc/rev displacement, 16 MPa rated pressure, and bidirectional rotation, ideal for forklifts and construction machinery. Backed by a Professional Manufacturer with 25+ years of experience and IATF 16949 certification, it ensures reliable OEM/ODM solutions and Factory Direct Sales quality.

سلسلة P21 مضخة التروس الهيدروليكية بارامترات
الإزاحة 64.6 سم³/دورة
الضغط المقنن 16 ميجا باسكال (2320 رطل لكل بوصة مربعة)
أقصى ضغط 17 ميجا باسكال (2465 رطل لكل بوصة مربعة)
السرعة المقننة 600 دورة/دقيقة
أقصى سرعة 2400 دورة في الدقيقة
الدوران ثنائي الاتجاه
المادة حديد زهر
البنية مضخة تروس خارجية
إصدار الحافة حافة بيضاوية A, حافة مربعة B, فتحات تثبيت ISO-4, فتحات تثبيت UNI-3, فلنج SAE
نوع العمود فتحة حلزونية X

**1. High-Efficiency Hydraulic Gear Pump Specifications**
- Delivers precise 64.6 cc/rev displacement with a rated pressure of 16 MPa (2320 psi) and max pressure of 17 MPa, ensuring stable power output for heavy-duty applications.
- Operates efficiently at a rated speed of 2000 r/min (max 2200 r/min) with bidirectional rotation capability, offering versatile installation options for diverse hydraulic systems.

**2. Versatile P21 Series Gear Pump Applications**
- Specifically engineered for material handling and earth-moving equipment, including forklifts, telehandlers, skid steer loaders, and backhoe loaders.
- Compatible with agricultural and industrial vehicles like tractors, sprayers, and waste compactors, providing a direct replacement for international mainstream brands with perfect fitment.

**3. Reliable Bidirectional Gear Pump Quality Control**
- Manufactured in our 68,000 sqm facility with 260+ vertical machining centers, every unit undergoes 100% bench testing for pressure, flow, and sealing integrity before shipment.
- Certified under IATF 16949 and CE standards, with SGS professional detection and 25+ autonomous patents, guaranteeing zero-defect performance and long service life.

**4. Customizable OEM/ODM Available Solutions**
- Supported by 35+ senior engineers with 10+ years of experience, we offer full customization including appearance, casting modifications, and exclusive logo laser marking for your Private Label needs.
- As a China Wholesale hub, we provide flexible OEM/ODM services to meet specific technical requirements, helping distributors build their own brand identity with Factory Direct support.

**5. Secure Factory Direct Sales & Logistics**
- Enjoy Wholesale Direct Sales advantages from a source factory with an annual capacity of 1,500,000 units, ensuring timely delivery and competitive pricing for bulk orders.
- Products are protected with anti-rust treatment and heavy-duty wooden crates/pallets, ensuring safe global transit and making us the preferred partner for Exported Worldwide projects.
