Private Label P40 Solenoid 2 Spool Monoblock Directional Valves

طريقة التحكم:ملف لولبي

الصمام:2 بكرة

معدل التدفق المقنن:40 لتر/دقيقة (10.5 جالون أمريكي في الدقيقة)

أقصى ضغط:250 بار (3600 رطل لكل بوصة مربعة)

منفذ الدخول:G1/2

منفذ الخروج:G1/2

حجم المنفذ:G3/8

العلامة التجارية:BXHS

نوع المنتج:صمام اتجاهي أحادي الكتلة

سلسلة المنتجات:سلسلة P40 صمام اتجاهي أحادي الكتلة

حجم العبوة:30*18*12

الوزن الإجمالي:6.50 kg

التوفر: متوفر بالمخزن

1088 شخصاً يشاهدون هذا المنتج

Private Label P40 Solenoid 2 Spool Monoblock Directional Valves

Private Label P40 Solenoid 2 Spool Monoblock Directional Valves

Private Label P40 Solenoid 2 Spool Monoblock Directional Valves drawing image

The P40 Series Solenoid 2 Spool Monoblock Directional Valve is a high-performance hydraulic valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. It features a compact design, robust construction, and reliable operation with a flow rate of 40 L/min and a maximum pressure rating of 250 bar.

سلسلة P40 صمام اتجاهي أحادي الكتلة بارامترات
طريقة التحكم يدوي, هوائي, كهروهوائي, كهروهيدروليكي, ملف لولبي, هيدروليكي, هيدروليكي ويدوي, كابل, ذراع تحكم, ملف لولبي وذراع تحكم, يدوي وذراع تحكم, ملف لولبي وكابل
الصمام 1 بكرة, 2 بكرة, 3 بكرات, 4 بكرات, 5 بكرات, 6 بكرات, 7 بكرات
نطاق درجة الحرارة المحيطة -40 درجة مئوية إلى +80 درجة مئوية (-40 درجة فهرنهايت إلى +176 درجة فهرنهايت)
نوع البنية صمام أحادي الكتلة
المقطع المقطع 1, المقطع 2, المقطع 3, المقطع 4, المقطع 5, المقطع 6, المقطع 7
نطاق اللزوجة التشغيلية 15 - 75 مم²/ث (15 سنتيستوك إلى 75 سنتيستوك)
معدل التدفق المقنن 40 لتر/دقيقة (10.5 جالون أمريكي في الدقيقة)
أقصى ضغط 250 بار (3600 رطل لكل بوصة مربعة)
منفذ الدخول G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
منفذ الخروج G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
حجم المنفذ G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

This P40 Series Solenoid 2 Spool Monoblock Directional Valve is a powerful hydraulic valve that offers precise control and efficient operation. With its compact monoblock structure, it's designed for easy installation and integration into various hydraulic systems. The valve features a 2 spool design with a rated flow of 40 L/min and a maximum pressure rating of 250 bar, making it suitable for demanding applications in material handling, construction, agriculture, and industrial vehicles. The valve's solenoid control provides reliable and responsive operation. It is also designed for a wide operating viscosity range and ambient temperature range, ensuring performance in various environments. This versatile valve is compatible with a wide range of applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, wheel loaders, backhoe loaders, and dumpers. We offer this valve for manufacturing, OEM, ODM, private label, and wholesale. We are also actively seeking distributors, wholesalers, agents, and traders to expand our global reach.
