Seeking Distributors and Wholesalers for P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump

الإزاحة:64.6 سم³/دورة

الضغط المقنن:16 ميجا باسكال (2320 رطل لكل بوصة مربعة)

أقصى ضغط:17 ميجا باسكال (2465 رطل لكل بوصة مربعة)

أقصى سرعة:2400 دورة في الدقيقة

الدوران:ثنائي الاتجاه

العلامة التجارية:BXHS

نوع المنتج:مضخة التروس الهيدروليكية

سلسلة المنتجات:سلسلة P21 مضخة التروس الهيدروليكية

حجم العبوة:45*25*18

الوزن الإجمالي:16.00 kg

التوفر: متوفر بالمخزن

165 شخصاً يشاهدون هذا المنتج

Seeking Distributors and Wholesalers for P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump

Seeking Distributors and Wholesalers for P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump

Seeking Distributors and Wholesalers for P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump drawing image

This P21 Series Hydraulic Gear Pump features a 64.6 cc/rev displacement, 16 MPa rated pressure, and bidirectional rotation, ideal for wheel loaders and excavators. Manufactured by a 25-year IATF 16949 certified factory with 1.5M annual capacity, it ensures reliable performance for construction and agricultural machinery.

سلسلة P21 مضخة التروس الهيدروليكية بارامترات
الإزاحة 64.6 سم³/دورة
الضغط المقنن 16 ميجا باسكال (2320 رطل لكل بوصة مربعة)
أقصى ضغط 17 ميجا باسكال (2465 رطل لكل بوصة مربعة)
السرعة المقننة 600 دورة/دقيقة
أقصى سرعة 2400 دورة في الدقيقة
الدوران ثنائي الاتجاه
المادة حديد زهر
البنية مضخة تروس خارجية
إصدار الحافة حافة بيضاوية A, حافة مربعة B, فتحات تثبيت ISO-4, فتحات تثبيت UNI-3, فلنج SAE
نوع العمود فتحة حلزونية X

**1. High-Efficiency Hydraulic Gear Pump Specifications**
- Delivers precise 64.6 cc/rev displacement with a rated pressure of 16 MPa (2320 psi) and max pressure of 17 MPa.
- Supports bidirectional rotation at speeds up to 2400 r/min, ensuring versatile integration into complex hydraulic systems.

**2. Professional Manufacturer with IATF 16949 Certification**
- Backed by 25+ years of expertise, 4 modern factories, and 260+ CNC machining centers for consistent quality.
- Every unit undergoes 100% bench testing for pressure, flow, and sealing, guaranteed by CE and SGS certifications.

**3. Versatile P21 Series Gear Pump Applications**
- Specifically engineered for heavy-duty equipment including wheel loaders, backhoes, skid steers, and forklifts.
- Perfectly compatible with major international brands, offering a cost-effective replacement solution for OEMs and distributors.

**4. OEM/ODM Available for Custom Branding**
- Supported by 35+ senior engineers, we offer tailored solutions including custom castings, logos, and private label services.
- Flexible manufacturing allows for specific port configurations and mounting flanges to meet unique project requirements.

**5. Factory Direct Sales with Global Logistics**
- Benefit from wholesale direct sales pricing with an annual production capacity of 1,500,000 units for fast lead times.
- Products are secured with anti-rust treatment and heavy-duty wooden crate packaging, ensuring safe worldwide delivery.
